Core Imaging Facility
Equipment
Zeiss LSM 710 Inverted Microscope with Temperature and CO2 Control Incubator
![CellSortingFacility_Visual1 CellSortingFacility_Visual1](/images/default-source/research/cellsortingfacility_visual1.jpg?sfvrsn=2f7b9d9b_2)
-
For fixed and live cells/tissues imaging
- Equipped for spectral imaging from blue to red fluorescence
- Objectives: 10x (LD), 20x (LD), 40x (LD), 63x (LD), 40x (oil), 63x (oil)
- Laser lines: 405nm, 458nm, 488nm, 514nm, 543nm, 633nm
- Temperature control incubator (5% CO2)
Zeiss LSM 980 Inverted Confocal with Airyscan 2
![LSM980 photo 2 LSM980 photo 2](/images/default-source/default-album/lsm980-photo-285c8ce60d9ba477e864fc32923fe3bea.jpeg?sfvrsn=9f7289f4_0&MaxWidth=450&MaxHeight=300&ScaleUp=false&Quality=High&Method=ResizeFitToAreaArguments&Signature=964D5688E5A773FDC5F0B266C8A00232994D5238)
- For fixed and live cells/tissues imaging
- Equipped with Airyscan 2 detector for efficient confocal spectral imaging in super resolution and multiplex mode
- Objectives: 10x, 20x, 40x (oil), 40x (water), 63x (oil), 100x (oil)
- Laser lines: 405nm, 445nm, 488nm, 514nm, 561nm, 594nm, 639nm
- Temperature control incubator
Applications
![CoreSortingFacility_Visual3_0 CoreSortingFacility_Visual3_0](/images/default-source/research/coresortingfacility_visual3_0.jpg?sfvrsn=35965e99_0)
Service
Confocal Microscope Training
The Confocal Micoscope Training is chargeable at S$170 (excl. gst). In addition, the core facility also host cutting edge imaging demo units when available.
Users would be required to possess a valid N3 license.
Confocal Microscope Booking
The use of confocal microscopes is chargeable at $25/hour. Cancellation of booking must be done at least 24 hours in advance to avoid incurring booking charges.
Location
Level 9, #09-46,
Duke-NUS Medical School,
8 College Road,
Singapore169857
